HIKMICRO Thermal Camera for Android Smartphones

R8,840.00

This is the recommended retail price.

Explorer – Thermal Camera for Smartphones

HIKMICRO Thermal Camera for Android Smartphones. The E20Plus is designed for consumer of applications of outdoor activities, like birdwatching, hiking, camping, sports and concerts. Equipped with functional HIKMICRO Sight App, E20Plus enables you to get the thermal imaging on your phone with USB type-C connector.

Download the HIKMICRO 2026 Product Brochure – Click here.

SKU E20Plus Categories ,

EXTENDED WARRANTY AND MAINTENANCE PLAN

PLAN INCLUDES THE FOLLOWING:

1. Extended warranty

– The HIKMICRO product warranty is extended from 3-years (36 months) to 5-years (60 months)

2. Thermal Africa maintenance package

Out-Of-Box Checks
– Pre-shipping checks.
– Pre-configuration of suggested menu settings.
– Updated firmware version.
– (Elimination of out-of-box failures – Video/LRF).
Swop-Out Policy
– Swop-out of faulty product after assessment – 24-48 hours turnaround time
– Replacement unit can be sent directly to the client.

3. Pricing:

– 10% of the product dealer purchase amount, excluding VAT.

TERMS AND CONDITIONS:
– Applicable to the Outdoor product range only.
– Stock will be ready for collection 24 hours after order payment is received.
– EWM Package must be included in initial product purchase – cannot be added afterwards.
– In the case of no new model available a refurbished model will be supplied.
– In case of NO fault found, all courier fee’s will be for the customer’s account.
– Should the exact model not be available the model closest will be provided.
– Products sent back has to be in the original packaging and with all accessories.
– Thermal Africa’s technical report is final.

PRODUCTS EXCLUDED FROM THE PLAN:
– Excludes batteries and chargers.
– Excludes Infra-red illuminators.
– Excludes Adapters and mounting brackets.

Description

HIKMICRO Thermal Camera for Android Smartphones.

The E20 Plus is a small and handy thermal imaging camera from HIKMICRO which specializes in manufacturing professional thermal equipment for industry, hunters and other outdoor activities. The small camera fits easily in your pocket and weighs only 26g. The camera can be easily attached to your phone and communicates via USB-C to your phone (Android only).

The camera can also be attached with a cable to the mobile to film narrow or inaccessible places where you cannot reach with your mobile phone, such as electrical cabinets, engines or pipes. The camera has a NETD value of ≤ 50 mK (at 25 degrees) a 9.7mm wide-angle lens and a detection distance of 980 m that allows you to see most things. Users can choose from six different palettes (Birdwatching/Red Hot/White Hot/Black Hot/Rainbow/Ironbow) and a refresh rate of 50Hz ensures a clear image.

Key Features

  • VOx uncooled focal plane arrays sensor with 256 × 192 resolution
  • NETD: ≤ 50 mK (@ 25°C, F# = 1.0)
  • Portable size: 26 g Weight
  • USB Type-C Interface (Android)
  • Support 3D DNR, image enhancement.
  • Support video recording and snapshot.

Technical Specifications

Thermal Module

  • Image Sensor: Vox uncooled focal plane arrays
  • Resolution: 256 × 192
  • Frame Rate: 50 Hz
  • Pixel Interval: 12 m
  • Response Waveband: 8 mm to 14 mm
  • NETD: ≤ 50 mk (@ 25°C, F# = 1.0)
  • Lens (Focal Length): 9.7 mm
  • Detection Range: 970 m
  • Aperture: F1.0
  • Magnification: 1× to 2x (Digital zoom 2x)
  • Field of View (H × V), Degrees/m @ 100 m: 18.1° × 13.6° / 31.8 M × 23.8 M



Image Display

  • Image Mode: Birdwatching/red hot/white hot/black hot/rainbow/ironbow
  • Contrast Adjustment: Adjustable contrast from 0 to 100 by slider control
  • Brightness Adjustment: Adjustable contrast from 0 to 100 by slider control



System

  • Record Video: Yes
  • Capture Snapshot: Yes
  • PIP: Yes
  • Digital Magnetic Compass: Yes
  • Hot Track: Yes



General

  • Power Supply: USB type-C interface
  • Power Consumption: 360 mw
  • Working Temperature: -10°C to 50°C
  • Dimension: 26.6 mm × 26.6 mm × 27.2 mm
  • Weight: 26 g
  • Protection Level: IP40

What's in the box

  • HIKMICRO Thermal Camera for Android Smartphones
  • Bag x1
  • Type-C Cable x1

Product Datasheet

Click HERE, to download the datasheet.
